Product Description
On-board graphics adapter dynamic frequency (max) 1150 MHz
Operating system architecture 64-bit
Warranty 5 Years
ECC No
Wi-Fi No
Intel 64 Yes
USB 2.0 ports quantity 4
Memory clock speeds supported by processor 2666 MHz
Processor model i5-10500
Processor lithography 14 nm
HP segment Business
Package depth 205 mm
SSD interface NVMe
Intel Trusted Execution Technology Yes
Idle States Yes
Thermal Monitoring Technologies Yes
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity 2
Intel Stable Image Platform Program (SIPP) Yes
Height 303 mm
Width 270 mm
Processor boost frequency 4.5 GHz
Processor cache 12 MB
Market positioning Business
Display included No
On-board graphics adapter Yes
Internal memory 16 GB
Scalability 1S
Intel® Secure Key Yes
Product type PC
Ethernet LAN data rates 10 -100 -1000 Mbit/s
Intel® Identity Protection Technology (Intel® IPT) Yes
PCI Express slots version 3.0
Optical drive type DVD-RW
HP JumpStart Yes
Combo headphone/mic port Yes
DisplayPort version 1.4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity 3
DVI port No
Mouse included Yes
Country of origin China
Processor threads 12
On-board graphics adapter DirectX version 12.0
Product colour Black
Embedded options available No
Motherboard chipset Intel Q470
Processor operating modes 64-bit
Processor socket LGA 1200 (Socket H5)
Microphone in No
Enhanced Intel SpeedStep Technology Yes
DisplayPorts quantity 1
Processor codename Comet Lake
Intel® Hyper Threading Technology (Intel® HT Technology) Yes
Total SSDs capacity 512 GB
Memory clock speed 2666 MHz
Thermal Design Power (TDP) 65 W
CPU configuration (max) 1
PCI Express configurations 1×16 -2×8 -1×8+2×4
Thermal solution specification PCG 2015C
Ethernet LAN Yes
On-board graphics adapter model Intel UHD Graphics 630
Intel® Quick Sync Video Technology Yes
Processor cores 6
Processor cache type L3
Processor ARK ID 199277
Maximum internal memory supported by processor 128 GB
Maximum number of PCI Express lanes 16
Chassis type SFF
SSD form factor M.2
Operating system installed Windows 10 Pro
On-board graphics adapter ID 0x9BC8
Number of displays supported (on-board graphics) 3
Intel Virtualization Technology for Directed I/O (VT-d) Yes
Intel VT-x with Extended Page Tables (EPT) Yes
Line-out Yes
Execute Disable Bit Yes
Weight 3.9 kg
On-board graphics adapter base frequency 350 MHz
Package height 499 mm
Memory types supported by processor DDR4-SDRAM
Memory layout (slots x size) 2 x 8 GB
Memory bandwidth supported by processor (max) 41.6 GB/s
Intel Software Guard Extensions (Intel SGX) Yes
Depth 95 mm
Intel® OS Guard Yes
Memory slots 2x DIMM
Maximum internal memory 64 GB
Processor frequency 3.1 GHz
Tjunction 100 C
Supported instruction sets SSE4.1 -SSE4.2 -AVX 2.0
Processor family 10th gen Intel Core i5
Package weight 6970 g
On-board graphics adapter OpenGL version 4.5
Internal memory type DDR4-SDRAM
Storage media SSD
Number of SSDs installed 1
Keyboard included Yes
Intel® Turbo Boost Technology 2.0
Discrete graphics adapter No
Intel® AES New Instructions (Intel® AES-NI) Yes
Card reader integrated No
HDMI ports quantity 1
HDMI version 1.4
Number of processors installed 1
Processor package size 37.5 x 37.5 mm
SSD capacity 512 GB
Intel® InTru™ 3D Technology Yes
Intel Clear Video Technology Yes
System bus rate 8 GT/s
HP Support Assistant Yes
Intel Virtualization Technology (VT-x) Yes
Discrete graphics adapter model Not available
Processor manufacturer Intel
Headphone outputs 1
Intel® Clear Video HD Technology (Intel® CVT HD) Yes
Maximum on-board graphics adapter memory 64 GB
Ethernet LAN (RJ-45) ports 1
Total storage capacity 512 GB
Package width 394 mm
